Feature overview
Technical parameter
walk | power | 11 (8.9) HP/2400rpm | |
speed | 0-3.5km/h (forward, backward) | Fuel tank volume | 11L |
Theoretical climbing ability | 25% | Lubricating oil | 1.3L |
Compact | Fuel consumption | 125g/kwh | |
Before static load/back | 61.5/65.5 n/cm | Size | |
Nominal amplitude | 0.5mm | Steel wheel width | 680mm |
Vibration frequency | 65Hz | Steel wheel diameter | 430mm |
Excitement | 17kn | Wheelbudie | 590mm |
Water tank volume | 25L | The chief (the armrest is flat) | 2480mm |
Work | Total width | 732mm | |
drive | Variable plunger pump, quantitative hydraulic motor | Total high (the armrest stands) | 1785mm |
vibration | Mechanical transmission, Electromagnetic clutch | Packed size | 1560 × 830 × 1910mm |
engine | weight | ||
model | G110 | Work weight | 840kg |
type | diesel engine, Water cooling |
Friendly reminder: Due to the continuous improvement and upgrading of the product, the content listed in this table cannot be changed simultaneously with the actual product. Therefore, this table cannot be identified as an attachment to the purchase contract. If necessary, technical parameters must be stated in the purchase contract.
