Model

Yanmar

Lifting height of screed

350mm

Type

Diesel, water-cooled 4-stroke, three-cylinder

Laser control system

Power

18.7kw / 3200 r / min

Control method

Microcomputer laser scanning

Oil capacity

2.1L

Control effect

Plane, slope or double slope (3D)

Fuel consumption

292g / kWh

Operation method

Walking system

Seat position

Front-loaded

Drive

Hydraulic motor

Forward, hind legs

Handle control, stepless speed change

Wheel

Solid anti-stab tire

Turn

Hydraulic control

Driving speed

0-30m / min

Cleaning system

Working speed

5m / min

Power

Hydraulic motor

Levelling head

Theoretical flow

20L / min

Type

Left / right swing / horizontal self-leveling

Preset pressure

7MPa

Slab width

2500mm

Input water pressure

0.5MPa

Paving way

Auger paving

Fuel capacity

30L

Auger Power

Hydraulic motor

Hydraulic oil capacity

40L

Vibration power

Hydraulic motor

Size and weight

Exciting force

600N

Maximum working size

2850 × 2950 × 2350mm

Vibration frequency

60HZ

Weight

1300kg
