You are here: Home » Product » Compact machinery » Walk behind double drum vibratory roller » RWYL35C » Walk-behind doubledrum road roller RWYL35C

Product Overview

Share to:

Walk-behind doubledrum road roller RWYL35C

Full hydraulic operation, French heavy-duty variable displacement piston pump, American cycloid hydraulic motor driven variable speed walking, hydraulic steering, Italian motor driven vibration, weight: 880kg

Quantity:

Features Overview

RWYL35CRWYL35C英文特征概述(1)


Technical Parameters

Run


Type

Diesel engine, air-cooled,  single cylinder

Speed

0-3.6km / h (forward and reverse)

Power

8.0hp / 3600rpm

Steering angle

± 15 °

Fuel tank volume

5.5L

Climbing capacity in theory

30%

Lubricant L

1.65L

Compaction


Fuel consumption

280g / kWh

Static load

62/65 N / cm

Dimension


Nominal amplitude

0.5mm

Width of steel drum

680mm

Vibration frequency

60Hz

Diameter of steel drum

355mm

Exciting force

20kN

Tread

650mm

Water tank volume

40L

Total length (keep handrail level)

2440mm

Working


Total width

755mm

Drive

Variable plunger pump, constant dispalcement hydraulic motor

Total height (keep handrail upright)

1800mm

Wibration

Hydraulic vibration

Packing size

1402 × 885 × 1167mm

Steering

Hydraulic steering

Weight


Engine


Working weight

880kg

Model

186F
