Features Overview
It integrates multiplefunction such as material suction and collection, nondestructine and loosening.Vaccum excavator have a history of proven performance in:
1.Underground utility and line location,Potholing, Keyholing,
2.Daylighting underground infrastructure, Water valve clean out.
3.Precise excavations, Excavation infrozen ground.
4.Pipe and line installation, Excavating in tight locations
Technical Parameters
Model | RWWJ11 | ||
Working | Run | ||
Vacuum pressure | -54kpa | Speed | 10-30km/h |
Digging depth | 2m/3.5m | Climbing capacity | 30% |
Suction depth | 4.5m | Turning radius | 6500mm |
Stoge tank volume | 1.8m³ | Turning mode | steering wheel |
Rubber hose diameter | 102mm | Cab capacity | 1 person |
Water systerm | Axles | 2 | |
Water tank volume | 800L | Wheel base | 2810mm |
Water pump pressure | 25Mpa | Wheel tread | 1610/1540mm (Forward/back) |
Flow of water pump | 21 L/Min | Quantity of tires | 6 |
Engine | Tyre size | 6.5R16 | |
Model | YANMAR 4TNV98T | Weight and Size | |
Type | Diesel, liquid cooles, four cylinder | Equipment weight | 5400kg |
Powe | 63.9kw/2500rpm | Working weight | 8000kg |
Fuel tank volume | 120L | Outline dimension | 5400×2090×2825mm |
Optional | Hydraulic Cutter,Hydraulic Breaker, Cab Air Conditioner | ||
